Camera Supraveghere Video Speed Dome Exterior 1 Megapixel HDCVI
Camera Supraveghere Video Speed Dome Exterior 1 Megapixel HDCVI
1455,63Lei
Fără TVA: 1203,00Lei
- Producator: Dahua Camere Analogice
- Model: Speed-Dome-Exterior-PTZ-Zoom-Optic12x-1Mp-HDCVI-Dahua
Produse vandute: 8
Features
Powerful 12x optical zoom
25/30/50/60fps@720P
DWDR, Day/Night (ICR), DNR (2D&3D), Auto iris, Auto focus, AWB, AGC, BLC
Max 300°/s pan speed, 360° continuous pan rotation
Control over coaxial cable, long distance real-time transmission
Up to 255 presets, 5 auto scan, 8 tour, 5 pattern
Built-in 2/1 alarm in/out
Support intelligent 3D positioning with DH-SD protocol
IP66,OSD
| Camera | |
| Image Sensor | 1/3” Exmor CMOS |
| Effective Pixels | 1280(H) x 960(V) |
| Scanning System | Progressive |
| Electronic Shutter Speed | 1/1 ~ 1/30,000s |
| Min. Illumination | Color: 0.05Lux F1.6; B/W: 0.005Lux@F1.6; 0Lux |
| S/N Ratio | More than 55dB |
| Resolution | 720P(25/30/50/60fps) |
| Video Output | 1-channel BNC HDCVI high definition video output |
| Camera Features | |
| Day/Night | Auto(ICR) / Color / B/W |
| Backlight Compensation | BLC / HLC / DWDR (Digital WDR) |
| White Balance | Auto, ATW, Indoor, Outdoor, Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | 2D/3D |
| Privacy Masking | Up to 24 areas |
| Digital Zoom | 16x |
| Lens | |
| Focal Length | 5.1mm~61.2mm(12x Optical zoom) |
| Max Aperture | F1.2~ F2.1 |
| Focus Control | Auto / Manual |
| Angle of View | H: 51.3° ~ 4.64° |
| Close Focus Distance | 100mm~ 1000mm |
| PTZ | |
| Pan/Tilt Range | Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1° ~300° /s; Tilt: 0.1° ~120° /s |
| Preset Speed | Pan: 240° /s; Tilt: 200° /s |
| Preset | 80(DH-SD), 255(Pelco-P/D) |
| PTZ Mode | 5 Pattern, 8 Tour, Auto Pan, Auto Scan |
| Speed Setup | Human-oriented focal length/ speed adaptation |
| Power up Action | Auto restore to previous PTZ and lens status after power failure |
| Idle Motion | Activate Preset/ Pan/ Scan/ Tour/ Pattern if there is no command in the specified period |
| Time Task | Auto activation of Preset/ Pan/ Scan/ Tour/ Pattern by preset-time |
| Protocol | DH-SD, Pelco-P/D (Auto recognition) |
| Audio | |
| Interface | 1 channel In |
| Auxiliary Interface | |
| RS485 | 1 |
| Alarm | 2/1 channel In/Out |
| General | |
| Power Supply | AC 24V/1.5A (±10%) |
| Power Consumption | 10W, 19W (Heater on) |
| Working Environment | -40ºC ~ 60ºC / Less than 90% RH |
| Ingress Protection | IP66 |
| Dimensions | Φ186(mm) x 234(mm) |
| Weight | 2.3kg |
